寶德BURKERT電磁閥類型說明

0330閥門是一種直接作用，介質分離的樞軸式電樞閥。它有3/2和2/2版本。作為3/2版本，它可以用作分配器或混合閥。根據應用，可以使用各種隔膜材料組合和操作方法。標準黃銅外殼滿足所有歐洲飲用水要求。不銹鋼（316L），PVDF和聚丙烯外殼版本*善了產品。電磁線圈采用耐化學腐蝕的環氧樹脂模制而成。 0330配有手動控制裝置，用于調試和測試。為了降低能量需求，所有線圈都可以通過電子功率降低或作為脈沖版本來提供?？梢杂梦恢梅答亴㈤_關狀態指示為二進制或NAMUR信號。與符合DIN EN 17301-803 A型的插頭組合使用時，閥門符合防護等級IP65 / 67  - 與不銹鋼或塑料外殼NEMA 4X組合使用。

直動式介質分離閥，直徑大DN 5

免維護的樞軸電樞技術

防振，塊螺紋線圈系統

適用于腐蝕性堿性和酸性溶液

服務友好，強大的手動操作

如需選擇正確的產品，請參閱技術數據，圖像和注釋，以便根據數據表正確使用。

BURKERT電磁閥00136350上海區域授權總**

Type Description

The 0330 valve is a direct-acting, media separated pivoted armature valve. It is available in 3/2- and 2/2-way versions. As a 3/2-way version, it can be used as a distributor or mixing valve. Various diaphragm material combinations and methods of operation are available depending on the application. The standard brass housing satisfies all European drinking water requirements. Stainless steel (316L), PVDF, and polypropylene housing versions complete the offering. The solenoid coils are moulded with a chemically resistant epoxy. The 0330 is equipped with manual override for commissioning and testing. For reduced energy requirements all coils can be delivered with electronic power reduction or as an impulse version. The switching status can be indicated with position feedback as a binary or NAMUR signal. In combination with a plug in accordance with DIN EN 17301-803 Form A, the valves satisfy protection class IP65/67 – in combination with a stainless steel or plastic housing NEMA 4X.

• Direct-acting, media separated valve with diameter of up to DN 5
• Maintenance-free pivoted armature technology
• Vibration-proof, block screwed coil system
• Suitable for aggressive alkaline and acidic solutions
• Service-friendly, robust manual operation
